Double surface planer IDC000147ENG

Double surface planer

• Manufacturer – Woodman
• Model – CR1100D
• Max. Width of planing – 1100 mml
• Min. Thickness of planing – 8 mm
• Max. Thickness of planing – 150 mm
• Min. Length of planing – 435 mm
• Bottom spindle speed – 4500 RPM
• Electric power – 75 kW
• Feed drive motor – 5 HP
• Pressure roller elevation motor – 2 HP|
• Dust hood outlet dimensions – O125 mm x 1, 200 mm x 4
• Cutter-head diameter – 150 mm
• Air pressure – 4~6 kg/cm
• Table height from floor – 990mm
• Machine dimensions (L x W x H) – 2800x2150x2000
• Net weight (Approx) – 4600 kgs
• Gross weight (Approx) – 4950 kgs
